ERD CCTV Power Supply 12v/10a Slim For 8ch PS40T
Tax included.
ERD CCTV Power Supply 12v/10a Slim For 8ch PS40T
ERD CCTV Power Supply 12v/10a Slim For 8ch (PS40T) is a slim and efficient power supply unit designed to deliver stable 12V/10A output, making it suitable for powering up to 8 CCTV cameras in compact surveillance installations. Its slim form factor allows easy fitting in tight spaces while ensuring reliable power
| Specification | Details |
|---|---|
| Input Voltage | 150V to 240V AC, 50/60Hz |
| Output Voltage | 12V DC |
| Output Current | 10 Amp (Max.) |
| Output Wattage | 120 Watt (Max.) |
| BIS Approved | Yes |
| SMPS IC Design | Highly Integrated Switcher I.C |
| Protections | Surge, Over Temp, Over Current, Over Voltage, Over Load |
| Efficiency | High Efficiency, Low Energy Consumption |
| Ripple Voltage | <5% (mV P-P) |
| Cable Compensation Switch | Yes, for Voltage Boosting |
| Design | Compact, Light Weight, Shock Proof |
| Color & Material | White FR Grade PC Cabinet |
| Cooling | Inbuilt Cooling Fan |
| Safety | Covered Input & Output Terminals |
| Mounting | Desktop Type with Wall Hanging Hook |
| Terminal Type | Screw Type Block Terminals |
| Applications | CCTV Camera, Other Electronic Equipment |
| Warranty | 1 Year (No physical/liquid damage) |
| Replacement Policy | Against Manufacturing Defects Only |
| Item Code | PS-40T |
