Feature	Specification
VAC Voltage	150~265VAC
Output Voltage	12VDC
Rated Power	36W
Ripple & Noise (max.)	70mV (max)
Voltage Adj. Range	NA
Device	Primary-Side Regulation CV/CC Switcher for Adapters and Chargers
Device (frequency)	85KHz
VDS Voltage	600V (max)
Line Regulations	±1%
Load Regulations	±5%
SCP	Output short-circuit protection
ARP	Auto-restart protection reduces power delivered by >90% for output short-circuit and control loop faults (open and shorted components)
ON/OFF Control	Provides constant efficiency down to very light loads – ideal for CEC regulations
Line UV	Line brown-in/out protection
OV	Line overvoltage shutdown extends line surge withstand
OTP	Accurate thermal shutdown, hysteretic or latching
Efficiency (Typical)	80%
Frequency Range	47~63Hz
Storage Temperature	0-50°C
