Rugtek LS-3002 2D Camera Barcode Scanner

Introducing the Latest Addition to the RUGTEK Series: 2D QR Barcode Scanner We are excited to unveil our newest innovation in the RUGTEK series: a state-of-the-art 2D QR Barcode scanner with a million-pixel scanning capability. This advanced scanner transcends traditional limitations, effortlessly capturing barcodes from mobile devices and even curved surfaces.

Features

• LED Indicator and Buzzer Sound: Provides clear feedback for successful scans.
• Excellent Decoding: Capable of scanning various complex codes with ease.
• Ergonomic Design: Ensures comfortable operation for extended use.
• Versatile Scanning: Supports both paper barcodes and QR codes on mobile screens.
• Durable Cable: High-temperature resistant material for longer life.
• Modular Design: Easy to assemble with strong drop resistance.

Explore the future of barcode scanning with our latest RUGTEK 2D QR Barcode scanner.

OS	Windows /iOS / Android / ChromeOS
Image Sensor	CMOS
Image(Pixels)	640 (H)*480 (v)pixels
Light source	Aiming: 625 nm RED LED / White Illumination 4000K White LED
Scan Mode	Handhand (Manual) / Handfree (Automatic )
Scan Rate	300 scans/second
Scan accuracy	≥4mil@ Code39
Print Contrast	≥20%
Visual Indicator	Red and Blue LED Light ,Buzzer
Interfaces	USB keyboard,USB virtual serial port,RS-232
Scan Angle	Left and right:± 55 °, Front and rear:± 55 °, Rotate:360 °
Field of view	32° horizontal, 24° vertical
Transmission Mode	Wired Transmission
Dimension (L x W x H)	1796894(mm)
Weight	203g(with cable)
Cable	Standard 1.8M straight
Power parameter	Input Voltage:5VDC±5%, Working corrent:150mA
Scan distance	20-200mm @ EAN 13mil PCS=100%:5-170mm @ QR 20mil PCS=100%
	Environmental parameters
Operating Temperature	-20°C~+ 60°C
Working Humidity	5% to 95% relative humidity, non-condensing
Storage Temperature	-40°C~+70°C
Electrostatic protection	±8 kV(Direct discharge)
Ambient brightness	0~100,000Lux
Drop Resistance	IP54 and2M
Safety regulations	CE (EN 55032:2015; EN 55035:2017), ROHS, EN62368-1:2014+A11:2017, FCC PART 15 CLASS B
	Decoding Capability
1D	EAN13, EAN8, UPC-A, UPC-E0􀉺UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code11, MSI-Plessey, Standard 2of 5, Plessey, China Post,Code 16K, GS1 Databar(RSS-Expand, RSS-Limited, RSS-14,GS1 Composite)
2D	QR, PDF417, DataMatrix(ECC200, Aztec, HanXinCode, Maxicode, Micro QR, Micro PDF417
